Degassing filter
Tianmiao degassing filter, the guardian of exhaust before the flow meter, automatically vents gas and intercepts impurities before liquid enters the meter. The float valve ensures precise opening and closing, and the filter screen precision can be selected as needed. Available in carbon steel and stainless steel, with sizes ranging from DN15 to DN600. Installed before the meter, it ensures accurate measurement.
Get a quote now for your personalized plan
Tianmiao degassing filters are suitable for liquid media with a viscosity ≤200 mPa·s, such as water, gasoline, diesel, crude oil, and edible oil. They are used in metering and conveying systems in industries such as petroleum, chemical, pharmaceutical, and food, providing a clean media environment for precision metering.
The equipment has a compact structure. After liquid enters the housing, it impacts the baffle plate, slowing the flow and causing gas to naturally rise to the top, forming an air chamber. Gas accumulation causes the liquid level to drop, triggering the float valve to open and release gas. After the gas is exhausted, the liquid level rises again, and the valve automatically closes, achieving continuous automatic degassing. Simultaneously, when the medium flows through the stainless steel filter screen, solid impurities are effectively trapped. The filtration accuracy can be flexibly selected between 10 mesh and 500 mesh depending on the actual operating conditions.
Material configuration is adaptable to requirements. The housing can be made of carbon steel, 304, or 316L stainless steel depending on the corrosiveness of the medium. The filter element and housing material are of the same grade to ensure long-term stable filtration performance. Sealing components are selected based on the operating temperature, using nitrile rubber, PTFE, or metal spiral wound gaskets. The applicable temperature range is -80℃ to 450℃. Our product specifications cover DN15 to DN600, with design pressures from 0.6MPa to 16.0MPa. Flange standards are compatible with various specifications such as GB, HG, SH, and ASME, meeting diverse engineering connection requirements.
Tianmiao Chemical Machinery possesses complete special equipment manufacturing qualifications. From raw material re-inspection and welding control to pressure testing, we implement standardized quality control throughout the entire process. Every piece of equipment undergoes pressure resistance and airtightness testing before leaving the factory.
We provide a one-stop, full-cycle service including selection and design, non-standard customization, and on-site guidance. Whether for new projects or upgrades to existing lines, we can tailor-make suitable solutions to help users improve metering accuracy and reduce operation and maintenance costs.
Degassing Filter Parameter Table
Parameter Series | Lab Level | Pilot Scale | Production Level |
Typical Nominal Diameter (DN) | 15 – 50 mm | 65 – 200 mm | 250 – 600 mm+ |
Design Pressure | 0.6 – 6.3 MPa | 0.6 – 10.0 MPa | 0.6 – 16.0 MPa (higher customizable) |
Design Temperature | -40°C ~ +150°C | -60°C ~ +250°C | -80°C ~ +450°C |
Core Material | 304/316L Stainless Steel | 316L Stainless Steel / PTFE Lined | 304/316L Stainless Steel / 316L Alloy / Carbon Steel |
Filtration Precision | 50 – 500 mesh (optional) | 30 – 500 mesh (optional) | 10 – 500 mesh (optional) |
Connection Mode | Thread / Small Flange | Flange / Butt Weld | Flange / Butt Weld (large diameter) |
Flow Range | 0.5 – 50 m³/h | 50 – 500 m³/h | 500 – 2000 m³/h+ |
